Hansen P4 Multistage - Horizontal

HANSEN P4 MULTISTAGE - HORIZONTAL

Overview:

* Specific horizontal housing - available in 19 sizes from 6 to 1100 kNm output Torque.
* Parallel and right Angle - 2/3/4 stage gearboxes with a wide range of reduction ratios.
* Service friendly with split plane, inspection cover and maintenance-free sealing system.
* Reliable product series allowing flexible customization and options upon request.
* Powerful Hansen P4 gear geometry for low noise and vibration levels.

Technical Info:

* Number of Sizes: 19.
* Housing type: Specific housings for horizontal applications.
* Gears: Helical and Bevel helical (in accordance with AGMA).
* Stages: 2, 3 or 4 stage.
* Reduction Ratios: 6.3:1 to 630:1 and special ratio's upon request.
* Nominal output torque: from 6 to 1100 kNm.
* Input speed: up to 1800 rpm.
* Shaft type: Solid or hollow low speed shaft.
* Lubrication: Splash lubrication.

Key Product Facts:

* Maximum Nominal output Torque (and even larger upon request): 1100 kNm.
* Parallel and Right Angle gearboxes: 19 sizes.
* A wide range of reduction ratios: 2-4 stages.

Advantages of Hansen P4 Horizontal Series:

* Dedicated Horizontal Housing: Stepped housing, better load distribution & easy access to mounting feet.
* Split Housing & Large Inspection Cover: Maintenance-friendly, easy inspection without oil drainage.
* Powerfull Gear Geometry: For maximum load capacity, minimum losses & lower noise levels.
* Maintenance-Free Sealing Systems: Oil-lock at the high speed shaft designed to keep the oil in and dirt out.
* Never a Dry Start-up:  Centralized oil filling guarantees initial oil lubrication at start-up. During operation, optimized splash lubrication with oil flow through the bearings.
* Instruments & Accessories: Condition monitoring instruments, Cooling devices & Complete Drive Packages (including base plates or lantern housings, motors, couplings,...).
